VOX to DXF Converter

Convert VOX files to DXF locally in your browser for faster handoff across 3D tools.

Processed locally
No signup required
Files stay on your device
Browser-local VOX to DXF conversion illustration

Private browser conversion

Files are converted locally in your browser.

1Upload2Convert3Download

Browser-local workflow

How this tool works

  1. Step 1

    VOX

    Choose a VOX file from this device.

  2. Step 2

    Browser-local conversion

    The supported geometry is converted in this browser.

  3. Step 3

    DXF

    Download the DXF result when conversion is complete.

Limited

  • Geometry

Lost

  • Vertex colors
  • Scene hierarchy
  • Units and scale

Direct answer

What is preserved when converting VOX to DXF?

This converter processes the VOX file locally in your browser and downloads the converted DXF file. The source is rewritten through the browser mesh pipeline. Vertex colors, scene hierarchy, and units and scale are not included in the downloaded file.

Before you convert

VOX to DXF compatibility

These results describe Modelfy's current browser loader and exporter, not every feature allowed by the file specifications.

Data preserved, limited, or lost when converting VOX to DXF
DataResultWhat this implementation does
GeometryLimitedThe custom writer exports triangle surfaces as R12 3DFACE entities, not editable CAD solids or curves.
MaterialsNot in sourceVOX does not define materials to carry into DXF.
TexturesNot in sourceVOX does not define textures to carry into DXF.
Vertex colorsNot exportedDXF output from this tool does not store vertex colors.
AnimationNot in sourceVOX does not define animation to carry into DXF.
Scene hierarchyNot exportedDXF output from this tool does not store scene hierarchy.
Units and scaleNot exportedThe VOX format can contain this data, but the current single-file loader does not retain it for conversion.

Verify after export

  • Confirm scale and units when opening the DXF file in the destination application.
  • Open the DXF in the destination CAD tool and confirm that triangle 3DFACE surfaces suit the workflow.

Why choose this VOX to DXF converter

Local VOX decoding

The selected VOX model file is decoded and rewritten as DXF on your device; the model file is not uploaded to Modelfy.

VOX to DXF data report

The compatibility table explains how this browser pipeline rewrites VOX data for DXF.

DXF output checks

Geometry is limited; review the implementation detail and verify the downloaded file in your destination tool.

Preview before export

Inspect the browser preview before converting, then use the post-export checklist to confirm the DXF result.

How to convert VOX to DXF online

  1. 01

    Upload your VOX file

    Drag and drop the file into the converter, or click Upload. VOX inputs up to 25 MB are processed locally.

  2. 02

    Convert to DXF

    Preview the model in 3D, then click Convert. The conversion runs locally in the browser; processing time depends on model complexity and device resources.

  3. 03

    Download the DXF file

    Your DXF file downloads straight to your device, ready for the next tool in your pipeline.

About the VOX file format

MagicaVoxel

The .vox format stores models as a grid of colored voxels plus a palette. It is the native format of MagicaVoxel, the most popular free voxel editor, used widely for stylized game art.

When converted to mesh formats, each voxel becomes cube geometry with its palette color preserved as vertex colors.

Format reference: MagicaVoxel VOX format description

Strengths

  • Compact voxel grid encoding
  • Palette colors preserved
  • Perfect for stylized game art

Commonly used for

  • Voxel art and stylized games
  • MagicaVoxel project exchange
  • Voxel-to-mesh conversion

About the DXF file format

Drawing Exchange Format

DXF was introduced by Autodesk in 1982 as an open, text-based twin of the DWG drawing format. It describes drafting entities — lines, polylines, arcs, circles — and 3D geometry as 3DFACE entities or polyface meshes.

This browser tool renders both: 2D drawings appear as line work, while 3DFACE and polyface entities render as solid meshes.

Format reference: Autodesk DXF reference

Strengths

  • Open, text-based CAD exchange
  • Universal 2D drafting support
  • 3DFACE mesh geometry support

Commonly used for

  • 2D drafting exchange
  • Laser cutting and CNC outlines
  • Legacy CAD data recovery

Frequently asked questions

Is my VOX model file uploaded to a server?

The selected VOX model file is processed by the browser and is not uploaded to Modelfy. Website code and static assets still load over the network like a normal web page.

Will I lose quality converting VOX to DXF?

Mesh geometry is preserved as closely as the DXF format allows. The target format may triangulate geometry or drop unsupported features such as animations, materials, textures, or scene hierarchy.

Is the VOX to DXF converter free to use?

Yes. The browser viewer, converter, and local 3D text tool require no account and add no watermark. Input limits vary by format, up to 50 MB; AI model generation is a separate credit-based product.

What is the maximum file size?

VOX inputs up to 25 MB are accepted. The format-specific limit keeps browser-local parsing bounded; actual processing also depends on available memory, model complexity, and device performance.

How are voxels turned into a 3D mesh?

Each solid voxel is meshed as cube faces with its palette color stored as vertex colors, so the converted GLB/OBJ keeps the voxel look. Interior faces between neighboring voxels are removed to keep the mesh lean.

Can a 2D DXF drawing be converted to a 3D model?

Drawings with closed polylines or circles are extruded into solid 3D shapes during conversion. Files containing only open curves (individual lines and arcs) have no enclosed area to extrude and cannot form a mesh.
